Measuring principle The sensor changes its conductivity proportionally with the number of molecules of reduced gases. The associated output voltage of the measuring element is amplified accordingly from 0 … 10 V. The greater the output signal of the sensor (0 … 10 V), the worse the air quality. Mixed-gas sensors are broad band, meaning the result of the sensor cannot be used to conclude neither the type of the gas not its concentration.
The sensor cannot differentiate between pleasant and unpleasant smells. It is the people in the area who must ultimately decide whether they are satisfied with the air quality.
Design standards In accordance with EN 60730-1:2002, CE conformity 2004/108/EC (electromagnetic compatibility) 2001/95/EC (product safety)
Supply voltage DC 15 ... 24 V / AC 24 V ± 10 %
Power input 1.2 W / 2.2 VA
Output signal 0 … 10 V (3-wire), min. load 10 kΩ
Operating temperature Ambient: -4...+122°F
Humidity range Max. 85 % r.h. (non-condensing)
Ingress protection IP 20 per EN 60529 / IEC 592 (with case)
Weight approx. 5.2 oz.
